Mersen OT75 Fuse OT - Class K5 - Fast-Acting 250VAC 250VDC 75A Blade Amp-Trap

Product Description

The MERSEN OT75 is a Fuse OT - Class K5 - Fast-Acting 250VAC 250VDC 75A Blade Amp-Trap®. These one-time general purpose fuses provide low cost protection for feeder and branch-circuits serving lighting, heating, and other non-motor loads. OT fuses will safely interrupt available short-circuit currents up to 50,000 amperes in all ratings.

• Low cost protection
• Interrupts available short-circuit currents up to 50,000 amperes
• Not rejection fuses

Product Highlights

The MERSEN OT75 fuse provides reliable, fast-acting protection for a variety of general purpose applications.

Product Information

Standard Information

• Brand: MERSEN
• Manufacturer Part Number: OT75
• Country of Origin: China

Technical Specifications

• Item number: OT75
• Description: Fuse OT - Class K5 - Fast-Acting 250VAC 250VDC 75A Blade Amp-Trap
• EAN/UPC Code: 782001700232
• Rated voltage AC UL: 250 V
• Rated voltage DC UL: 250 V
• Frequency (Hz): 50/60 Hz
• Ampere Rating: 75 A
• AC or DC: AC/DC
• Fuse Class: Class K5
• Speed/Characteristic: Fast-Acting
• Mounting: Clip
• AC Max I.R./Breaking Capacity: I1: 50 kA
• Connection/Terminal Material: Tin-Plated Copper
• Connection/Terminal Type: Blade
• Product Diameter: 1.06 in
• Product Length: 5.88 in
• Product group: Low Voltage UL/CSA Fuses
• Body/Insulating Material: PolyTube
• Ampere: 75 A
• Voltage rating: 250 Vac, 250 Vdc
• Interrupt rating: 50 kA
• Speed: Fast-Acting
• Class: Class K5
• Shape: Cartridge Blade Fuses
• Approvals: UL, CSA, RoHS
• Brand: Mersen
• Country of Origin: China
