Mersen MPDB69133 MPDB Series UL 1953 1000V 500A - 620A AL Large 3-Pole 2 - 6 350-#6 2/0-#14

Product Description

The Mersen MPDB69133 is an open-style power distribution block designed for industrial applications. This device operates at a voltage rating of one thousand volts and can handle amperages up to six hundred twenty amps. It is built from tin-plated aluminum and features three poles with multiple connection options.

• UL Listed to subject 1953, File E352417
• Splicing cables and splitting power into secondary circuits
• Includes optional adder poles for customized configurations

Product Highlights

The Mersen MPDB69133 is essential for effective power distribution in various electrical setups, ensuring safe and reliable connections.

Product Information

Standard Information

• Brand: Mersen
• Manufacturer: Mersen

Technical Specifications

• Catalog Number: MPDB69133
• Amperage Rating: 620
• Voltage Rating: 1000
• Material: Tin-plated Aluminum
• Connection: Box To Box
• Country of Origin: Mexico
• Size: 5.7 x 7.89 x 3.55 inches
• Application: Suitable for various splicing and power distribution tasks.
