Mersen MPDB68313 FER Power Distribution Block 600 VAC 760 A 3 Poles 4 AWG to 500 kcmil

Product Description

The Mersen MPDB68313 is a power distribution block designed for effective cable management and splitting of primary power into secondary circuits. This component is rated for six hundred volts AC and can handle up to seven hundred sixty amps. It features three poles that provide versatility in wiring configurations.

• UL and CSA approved for safe operation
• Allows for customization through stackable adder poles
• Constructed with durable polycarbonate material

Product Highlights

The MPDB68313 is excellent for applications including cable splicing and creating fixed junction tap-off points. The design supports connection of up to four secondary wires per pole, allowing for efficient circuit management.

Product Information

Standard Information

• Brand: Mersen
• MPN: MPDB68313

Technical Specifications

• Voltage Rating: 600 VAC
• Amperage Rating: 760 A
• Number of Poles: 3
• Primary Connections/Pole: 2
• Secondary Connection/Pole: 4
• Wire Size: 4 AWG to 500 kcmil, 10 to 4/0 AWG
• Dimensions: 7.89 in W x 5.7 in D x 4.75 in H
• Material: Polycarbonate
• Short Circuit Current Rating: 100 kA
