Mersen MPDB67673 MPDB Series UL 1953 1000V 250A - 310A AL INT 3-Pole 1 - 4 350-#6 #2-#14

Product Description

The Mersen MPDB67673 is a three-pole power distribution block. This product supports voltages up to one thousand volts and has an amperage rating of three hundred and ten amps. The design features tin-plated aluminum, which enhances its durability and conductivity.

• Works with box-to-box connections.
• Offers openings sized for conductors from three hundred fifty to #6 and #2 to #14.
• Compliant with UL 1953 standards.

Product Highlights

This power distribution block is ideal for splicing cables and splitting primary power into secondary circuits. It aids in creating fixed junction tap-off points effectively.

Product Information

Standard Information

• Manufacturer: Mersen
• Country of Origin: Mexico

Technical Specifications

• Catalog Number: MPDB67673
• Voltage Rating: 1000 volts
• Amperage Rating: 310 amps
• Material: Tin-plated aluminum
• Size: 3.08 x 5.28 x 3.25 inches
• Mounting: Screw
• Special Features: Optional adder poles for flexibility; insulators made of glass-filled polycarbonate; meets feeder and branch circuit application requirements.
• UPC: 782001452889
• GTIN: 00782001452889
