Mersen MPDB67592 FER Power Distribution Block 600 VAC 175 A 2 Poles 14 to 2/0 AWG Line 14 to 6 AWG Load

Product Description

The Mersen MPDB67592 Power Distribution Block is designed for effective cable splicing and power distribution. This intermediate open-style block supports voltage ratings of six hundred volts alternating current (VAC) and current ratings of one hundred seventy-five amperes (A). It accommodates two poles and is suitable for wire sizes ranging from fourteen to two/aught AWG for line and fourteen to six AWG for load wire. Mersen's MPDB Series provides reliable performance across various electrical applications.

• UL and CSA approved for safety and reliability.
• Customizable with adder poles for flexibility in configurations.
• Meets spacing requirements for feeder and branch circuits.

Product Highlights

This product is ideal for splitting primary power into secondary circuits and forming junction tap-off points. The construction incorporates durable polycarbonate material, providing long-lasting performance even in demanding conditions.

Product Information

Standard Information

• Brand: Mersen
• Part Number: MPDB67592

Technical Specifications

• Voltage Rating: 600 VAC
• Current Rating: 175 A
• Number of Poles: 2
• Primary Connections per Pole: 1
• Secondary Connections per Pole: 10
• Wire Sizes: 14 to 2/0 AWG Line, 14 to 6 AWG Load
• Short Circuit Current Rating: 100 kA
• Dimensions: 5.28 in W x 1.72 in D x 3.25 in H
• Material: Polycarbonate
• Country of Origin: Mexico
