Mersen MPDB66552 Intermediate Open Style Power Distribution Block 1000 VAC/VDC (350 A) MPDB66552

Product Description

The Mersen MPDB66552 is an Intermediate Open Style Power Distribution Block designed for effective power management in electrical systems. This power distribution block operates at a voltage rating of one thousand VAC/VDC and handles a maximum current of three hundred fifty amperes. It features two poles and accepts wire sizes ranging from fourteen to two/zero AWG. This product is ideal for applications in cable splicing, splitting primary power into secondary circuits, and for use as fixed junction tap-off points.

• UL and CSA approved for safety
• Accommodates two primary connections per pole and up to fifteen secondary connections
• Polycarbonate construction adds durability and functionality

Product Highlights

The Mersen MPDB66552 supports flexible wiring options with stackable adder poles that enable customization for various electrical needs.

Product Information

Standard Information

• Brand: Mersen
• Manufacturer: Mersen

Technical Specifications

• Voltage Rating: 1000 VAC/VDC
• Amperage Rating: 350 A
• Number of Poles: 2
• Primary Connections/Pole: 2
• Secondary Connections/Pole: 15
• Wire Size: 14 to 2/0 AWG
• Short Circuit Current Rating: 100 kA
• Dimensions: 3.57 in L x 4 in W x 2.62 in H
• Material: Polycarbonate
• Country of Origin: Mexico
