Mersen MPDB63193 Miniature Open Style Power Distribution Block 600 VAC 175 A 3 Poles 14 to 2/0 AWG

Product Description

The Mersen MPDB63193 is a miniature open style power distribution block that operates at 600 VAC and supports up to 175 A. It is designed for safe splicing of cables and splitting primary power into secondary circuits. This block is suitable for applications requiring fixed junction tap-off points. It has three poles and can accommodate wire sizes from 14 AWG to 2/0 AWG.

• Rated at 600 VAC with a 175 A amperage capacity
• Compatible with 14 to 2/0 AWG wire
• UL and CSA approved, meets spacing requirements for feeder and branch circuits

Product Highlights

The MPDB63193 offers a sturdy construction with tin-plated aluminum materials. Its design allows for easy mounting and provides effective dead-front protection.

Product Information

Standard Information

• Catalog Number: MPDB63193
• Manufacturer: Mersen

Technical Specifications

• Voltage Rating: 600 VAC
• Amperage Rating: 175 A
• Number of Poles: 3
• Wire Size: 14 to 2/0 AWG
• Material: Polycarbonate and tin-plated aluminum
• Dimensions: 2.91 inches wide x 3.08 inches deep x 2.81 inches high
• Connection Type: Box to Box
• Country of Origin: Mexico
