Mersen GGM10 GGM fast-acting glass fuse 10 amps 250V 5mm x 20mm 5-pack

Product Description

The MERSEN GGM10 is a fast-acting miniature fuse designed for electronic circuits. This GGM series fuse features a cylindrical glass body with a 5 mm diameter and 20 mm length, rated for 10 Amps at 250 VAC. It offers a 0.1 kA interrupt rating and utilizes a ferrule terminal with clip mounting.

• Nickel-plated brass contact for reliable conductivity.
• Fast-acting characteristic with a 0.1 kA interrupt rating.
• Glass body construction with 5 mm x 20 mm dimensions.

Product Highlights

This miniature fast-acting fuse is suitable for protecting electronic circuits.

Product Information

Standard Information

• Brand: MERSEN
• Manufacturer Part Number: GGM10
• Country of Origin: China

Technical Specifications

• Fuse Type: Miniature
• Fuse Class: Supplemental
• UNSPSC Code: 39121600
• Color: Clear
• Series: GGM Series
• Body Material: Glass
• Body Type: Cylindrical
• Mounting Type: Clip
• Terminal Type: Ferrule
• Voltage Rating: 250 VAC
• Current Rating: 10 A
• Interrupt Rating: 0.1 kA
• Country of Origin: CN
• Rejection/Non-Rejection: Non-Rejection
• Characteristic: Fast Acting
• Application: Electronic Circuits Applications
• Made in USA: No
• UPC: 782001762247
• AC or DC: AC
• Pack Quantity: 5 EA
• Product Group: Miniature Fuses
• ASIN: B005QDU2P4
• Certifications: UL Recognized, CE
• Family Series: Mersen Fuses, GGM Series
• Trip Indicator: No
• Alarm Contacts: No
• Package Type: Cartridge
• Alternate Mfr Part Number: Y216520
