Mersen GDL8 Time Delay Miniature Fuse 8 A 250 VAC 1/4 In Dia X 1-1/4 In L

Product Description

The MERSEN GDL8 is a time delay miniature fuse designed for electronic circuit applications. This 8 A, 250 VAC fuse features a 0.2 kA interrupt rating and a cylindrical glass body measuring 1/4 inch diameter by 1-1/4 inches long. It utilizes a ferrule terminal and clip mount for installation, providing reliable overcurrent protection.

• Time delay characteristic for managing transient current spikes in electronic circuits.
• Rated for 8 A and 250 VAC with a 0.2 kA interrupt capacity for effective circuit protection.
• Features a 1/4 inch diameter by 1-1/4 inch long cylindrical glass body with ferrule terminals.

Product Highlights

UL Listed and RoHS Compliant, this miniature fuse includes nickel-plated brass contacts for enhanced conductivity in electronic circuits.

Product Information

Standard Information

• Brand: MERSEN
• Manufacturer Part Number: GDL8
• Country of Origin: China

Technical Specifications

• Amperage Rating: 8 A
• Application: Electronic Circuits Applications
• Body Size: 1/4 in Dia x 1-1/4 in L
• Body Type: Cylindrical
• Color: Clear
• Element: Single
• Equivalent Fuse Series: GDL & MDL
• Fuse Class: Supplemental
• Indicating/Non-Indicating: Non-Indicating
• Interrupt Rating: 0.2 kA
• Material: Glass
• Mounting Type: Clip
• Product Group: Miniature Fuses
• Rejection/Non-Rejection: Non-Rejection
• Series: GDL
• Standards: RoHS Compliant | UL Listed | CSA 248-14
• Terminal Type: Ferrule
• Type: Time Delay
• Voltage Rating: 250 VAC
• Voltage Type: AC
