Product Description
The Mersen GDL15 is a time delay glass midget fuse with a rating of fifteen amps and one hundred twenty-five volts. It has a size of 6.3mm by 32mm and is designed to protect electronic circuits from overload and short circuits.
- Time-delay design allows for temporary overcurrent conditions.
- UL Listed and CSA Certified for safety.
- Suitable for use in miniature fuse applications and electrical equipment.
Product Highlights
This miniature fuse effectively prevents damage to your electrical systems by controlling overload conditions.
Product Information
Standard Information
Technical Specifications
-
Voltage Rating: 125V
-
Amperage Rating: 15 A
-
Size: 1.25 x 0.25 in
-
Type: 6x32mm, 1/4 x 1-1/4
-
Mounting: Clip
-
Class: Supplemental
-
Interrupt Rating: 10 kA
-
Application: Electronic circuits
