Mersen GDL1/16 time delay miniature fuse 0.0625 A 250 VAC 1/4 inch dia x 1-1/4 inch L Bussmann MDL

Product Description

The MERSEN GDL1/16 is a time delay miniature fuse designed for electronic circuits. This 0.0625 A, 250 VAC fuse features a cylindrical glass body measuring 1/4 inch Dia x 1-1/4 inch L, with a single element. It is non-indicating and non-rejection, utilizing a ferrule terminal and clip mounting. This cartridge-style fuse tolerates temporary inrush currents, preventing nuisance-blowing from equipment startups and providing overcurrent protection for low-current applications.

• Nickel-plated brass contact for reliable conductivity.
• Time delay characteristic prevents nuisance-blowing from temporary inrush currents.
• Cylindrical glass body allows visual inspection of the fuse element.

Product Highlights

MERSEN GDL1/16 time delay miniature fuse for overcurrent protection in electronic circuits, appliances, and lighting fixtures.

Product Information

Standard Information

• Brand: MERSEN
• Manufacturer Part Number: GDL1/16
• Country of Origin: China

Technical Specifications

• Application: Electronic Circuits Applications
• Series: GDL
• Element Type: Single
• Body Material: Glass
• Body Dimensions: 1/4 inch Dia x 1-1/4 inch L
• Body Type: Cylindrical
• Mounting Type: Clip
• Terminal Type: Ferrule
• Voltage Rating AC: 250 VAC
• Current Rating: 0.0625 A
• Interrupt Rating: 0.035 kA at 250 VAC, 10 kA at 125 VAC
• Country of Origin: China
• Rejection Type: Non-Rejection
• Indication Type: Non-Indicating
• Certifications: RoHS Compliant, UL Listed, CSA 248-14
• Fuse Type: Time Delay
• Voltage Rating DC: Not Rated
• Fuse Class: Supplemental
