Mersen ATQR6 Fuse ATQR - Class CC - Time-Delay 600VAC 300VDC 6A Ferrule

Product Description

The Mersen ATQR6 is a Class CC time-delay fuse designed for control transformers, solenoids, and inductive loads. It is ideal for applications requiring protection against high inrush currents without nuisance tripping. The fuse operates at a 600VAC and 300VDC rating and features a 6A amperage rating.

• Time-delay design suitable for control transformers and solenoids.
• Highly current limiting to minimize peak let-through current.
• Rejection-style design to prevent installation errors.

Product Highlights

This fuse is known for its reliability in protecting electrical circuits in industrial settings. It features a fiberglass body for dimensional stability and is filled with high-grade silica to ensure quick arc quenching and high current limitation.

Product Information

Standard Information

• Brand: Mersen
• Series: Amp-Trap 2000

Technical Specifications

• Voltage Rating: 600VAC/300VDC
• Amperage Rating: 6A
• Interrupt Rating: 200 KA
• Mounting Type: Clip
• Terminal Type: Ferrule
• Body Size: 13/32 in dia x 1-1/2 in L
• Standard: UL listed to standard 248-4 File E2137, DC listed to UL standard 248, CSA certified to standard C22.2 No. 248.4
