Mersen ATQR5 Fuse ATQR - Class CC - Time-Delay 600VAC 300VDC 5A Ferrule

Product Description

The Mersen ATQR5 is a Class CC time-delay fuse designed for multiple applications. It operates at a voltage rating of 600 volts AC and 300 volts DC with a current rating of 5 amps. This fuse is ideal for use in control transformers, solenoids, inductive loads, and general-purpose applications.

• Class CC design provides efficient protection
• Time-delay features to handle inrush currents
• High interrupt rating of 200 KA for safety

Product Highlights

This fuse ensures reliable performance in demanding environments. Its rejection-style design prevents installation errors, and its fiberglass body offers stability in harsh conditions.

Product Information

Standard Information

• Brand: Mersen
• Catalog Number: ATQR5

Technical Specifications

• Amperage Rating: 5 A
• Voltage Rating: 600 VAC / 300 VDC
• Interrupt Rating: 200 KA
• Connection Type: Ferrule
• Mounting Type: Clip
• Country of Origin: Mexico
• UL Standard: 248-4
• Application: Control transformers, solenoids, inductive loads, lighting, heating, and general-purpose loads
