Mersen ATMR1/4 Current Limiting Low Voltage Fast Acting Fuse, 0.25 A, 600 VAC/VDC, 200/100 kA, Class CC

Product Description

The Mersen ATMR1/4 is a current limiting low voltage fast acting fuse with an amperage rating of 0.25 A. It is designed for use in circuits rated up to 600 VAC and 600 VDC. This fuse is part of the Class CC family which is widely used for branch circuit protection.

• Fast acting capabilities for immediate current interruption.
• Rejection dimensions ensure it cannot be replaced with lower-rated fuses.
• Suitable for control circuits where available short circuit currents exceed 10,000 A.

Product Highlights

The ATMR1/4 fuse provides reliable protection for electrical circuits, specifically designed to handle high short-circuit currents. Its rejection style design prevents incorrect substitutions during installation.

Product Information

Standard Information

• Manufacturer: Mersen
• Part Number: ATMR1/4

Technical Specifications

• Voltage Rating: 600 VAC/VDC
• Interrupt Rating: 200/100 kA
• Amperage Rating: 0.25 A
• Body Size: 13/32 in Dia x 1-1/2 in L
• Body Type: Cylindrical
• Mounting Type: Clip
• Terminal Type: Ferrule
• Application: Control circuits, general loads, and branch circuit protection
