Mersen ATM15 Low Voltage Fast Acting Fuse 15 A 600 VAC/VDC 100 kA

Product Description

The Mersen ATM15 is a low voltage fast acting fuse with a rating of fifteen amperes and capable of handling up to six hundred volts for both AC and DC applications. Designed with a cylindrical body and a clip mount, this fuse is suitable for various electrical applications, particularly where quick responses are needed to prevent overloads.

• Rated interrupting capacity of one hundred kiloamperes.
• Non-indicating, single element design for reliable performance.
• Appropriate for supplemental protection of small motors and transformers.

Product Highlights

The ATM15 is engineered for situations where standard fuses may not suffice. With its ability to withstand high inrush currents, it is ideal for various high-demand applications, including capacitor protection.

Product Information

Standard Information

• Brand: Mersen
• MPN: ATM15

Technical Specifications

• Rating Voltage: 600 VAC/VDC
• Amperage Rating: 15 A
• Interrupt Rating: 100 kA
• Response Time: 35 s
• Mounting Type: Clip
• Terminal Type: Ferrule
• Body Size: 13/32 in Dia x 1-1/2 in L
• Series: ATM
