Mersen ATM1 Midget Fuse Fast Acting 1 AMP Each

Product Description

The Mersen ATM1 is a fast-acting midget fuse rated for one ampere. It provides protection for circuits up to six hundred volts AC and DC. These fuses are designed with a one hundred kiloamp interrupting rating, ensuring reliable operation under high fault conditions.

• Rated for six hundred volts AC and DC.
• Interrupting rating of one hundred kiloamps.
• Fast-acting design for immediate protection.

Product Highlights

This fuse is ideal for supplemental protection of small motors and transformers. Its fast-acting nature ensures quick reaction to fault conditions, helping to prevent damage to electrical components.

Product Information

Standard Information

• Manufacturer: Mersen
• Part Number: ATM1

Technical Specifications

• Amperage Rating: 1 A
• Voltage Rating: 600 VAC/VDC
• Interrupt Rating: 100 kA
• Mounting Type: Ferrule
• Body Size: 13/32 in diameter x 1-1/2 in length
• Standards and Approvals: UL File No. E33925, C22.2 No. 248.14
• Country of Origin: Mexico
