Mersen ATDR7 Time-Delay Fuse 7A 600VAC 300VDC Class CC Fuse

Product Description

The Mersen ATDR7 is a versatile and robust time-delay class CC fuse, designed to handle 600 volts AC and 300 volts DC with a 7A current rating. Suited for intricate electrical setups requiring precise timing and protection, the ATDR7 fuse helps prevent circuit overload by providing a consistent performance under variable current conditions. This fuse is specially engineered with a dual element, allowing it to sustain temporary overloads without opening, making it a reliable choice for commercial and industrial settings.

• Features a 200 KA interrupt rating highlighting its strong fault current protection.
• Includes a ferrule mounting type, ensuring secure installation and maintaining connection integrity.
• Constructed from high-grade silica and a fiberglass body, it guarantees durability and resistance against environmental extremities.

Product Highlights

This fuse is optimized for devices with high inrush currents, such as motors and commercial lighting. Its time-delay functionality prevents nuisance tripping during momentary overloads, thereby enhancing circuit safety.

Product Information

Standard Information

• Brand: Mersen
• Mounting Type: Ferrule

Technical Specifications

• Voltage Rating: 600V AC / 300V DC
• Amperage: 7A
• Interrupt Rating: 200 KA
• Size: 1.5 inches x 0.41 inches
• Material: Fiberglass and Silica
• Standards: UL listed, CSA certified
• Special Features: Highly current-limiting, rejection-style design, metal-embossed date
