Mersen ATDR6 ATDR - Class CC time-delay, low voltage UL/CSA fuse, 6 Amps, 600V

Product Description

Mersen ATDR6 is a Class CC time-delay fuse designed for low voltage applications. This fuse accommodates six amps and operates at six hundred volts. It enhances protection for sensitive electrical components and small motors, mitigating risk associated with fault-related damage.

• Time-delay for managing motor starting inrush currents.
• Developed to limit low peak let-through current.
• Supports frequent motor starts and stops without nuisance openings.

Product Highlights

This fuse is ideal for branch circuit protection in various industrial and commercial settings.

Product Information

Standard Information

• Type: FUSES
• Fuse Types: LOW VOLTAGE

Technical Specifications

• Voltage Rating: 600 VAC
• Amperage Rating: 6 A
• Interrupt Rating: 200 kA
• Mounting Type: Ferrule
• Material: Fiberglass
• Application: Small motors, Contactors, Lighting, Heating, General loads
• Specifications Standards: UL listed to standard 248-4, CSA certified to standard C22.2 No. 248.4
