Mersen ATDR10 Fuse ATDR - Class CC - Time-Delay 600VAC 300VDC 10A Ferrule

Product Description

The Mersen ATDR10 is a time-delay fuse designed for use in Class CC applications. It operates at a voltage of six hundred volts AC and three hundred volts DC with an amperage rating of ten amps. This fuse is suitable for protecting small motors, lighting, heating, and general loads.

• Time delay feature for inrush currents
• Ferrule connection type
• Interrupt rating of two hundred kiloamperes

Product Highlights

This fuse offers a rejection-style design to prevent incorrect replacements and features a high visibility orange label for easy identification.

Product Information

Standard Information

• Catalog Number: ATDR10
• Manufacturer: Mersen

Technical Specifications

• Amperage Rating: 10
• Voltage Rating: 600
• Application: Small motors, contactors, lighting, heating, general loads
• Mounting: Clip
• Interrupt Rating: 200 KA
• Connection: Ferrule
• Special Features: Time-delay for motor starting inrush currents, high-grade silica filler for fast arc quenching
• Country of Origin: Mexico
