Mersen ATDR1-1/2 Fuse ATDR - Class CC - Time-Delay 600VAC 300VDC 1.5A Ferrule

Product Description

Mersen ATDR1-1/2 is a Class CC fuse suitable for a variety of electrical applications. This time-delay fuse supports a voltage of six hundred volts AC and three hundred volts DC with an amperage rating of one point five amps. It adheres to UL and CSA standards, ensuring reliability in critical environments.

• Time-delay for inrush current management
• Interrupt rating of two hundred kiloamperes
• Manufactured with a fiberglass body for durability

Product Highlights

This fuse is ideal for small motors, lighting, and branch circuit protection. Its time-delay feature allows for a smooth startup without nuisance tripping.

Product Information

Standard Information

• Manufacturer: Mersen
• UPC: 782001908508

Technical Specifications

• Catalog Number: ATDR1-1/2
• Application: Small motors, contractors, lighting, and general loads
• Connection: Ferrule
• Voltage Rating: 600 VAC, 300 VDC
• Amperage Rating: 1.5 A
• Interrupt Rating: 200 KA
• Mounting: Clip
• Body Type: Fiberglass
• Special Features: Time-delay for motor starting inrush currents, highly current-limiting, improved cycling ability, high-visibility orange label, metal-embossed date and catalog number
