Mersen A6T100 Fuse A6T - Class T - Fast-Acting 600VAC 300VDC 100A Blade

Product Description

Mersen A6T100 is a fast-acting, current-limiting fuse designed for use in electrical systems. It operates at a voltage rating of six hundred volts alternating current and three hundred volts direct current, with a capacity of one hundred amps. This fuse is suitable for load centers, panel boards, switchboards, circuit breakers, and metering centers.

• Voltage rating: 600VAC, 300VDC
• Amperage rating: 100A
• Interrupt rating: 200 kA at 600VAC, 100 kA at 300VDC

Product Highlights

This fuse features unique dimensions that prevent the substitution of lower-rated fuses. Its design offers a small physical footprint while allowing for effective current limitation.

Product Information

Standard Information

• Catalog Number: A6T100
• Manufacturer: Mersen

Technical Specifications

• Voltage Rating: 600V AC, 300V DC
• Amperage Rating: 100A
• Interrupt Rating: 200 kA
• Mounting Type: Blade
• Body Size: 2.95 inches x 0.82 inches
• Application: Load centers, Panelboards, Switchboards, Circuit Breakers
• Country of Origin: Mexico
• UPC: 782001891435
