Mersen A30QS600-4 High Speed Fuse Amp-Trap 300VAC 300VDC 600A Blade

Product Description

The Mersen A30QS600-4 is a high-speed fuse designed for protecting power semiconductor devices. This fuse is suitable for applications requiring protection of circuits operating at voltages up to three hundred volts. Often used in heavy-duty equipment, it provides reliable circuit protection in critical systems.

• Amperage Rating: Six hundred amperes
• Voltage Rating: Three hundred volts AC and DC
• Interrupt Rating: Two hundred kA at three hundred volts AC and one hundred kA at three hundred volts DC

Product Highlights

This fuse features a low I2T characteristic, minimizing damage during short circuits. The controlled arc voltage reduces stress on circuit components while clearing fuses. Its versatile mounting options enhance utility in system designs.

Product Information

Standard Information

• Catalog Number: A30QS600-4
• Manufacturer: Mersen

Technical Specifications

• Application: Protection of AC/DC drives, UPS, and other equipment of three hundred volts or less
• Connection Type: Blade
• Mounting Type: Bolt-On
• Body Style: Cylindrical
• Body Size: One point five inches diameter by three point eight four inches length
• Material: Ceramic
• Standard: UL recognized component, UL File E60314
• UPC: 782001280895
• GTIN: 00782001280895
