MERSEN 82944 5A500V ATQ Fuse

Product Description

The MERSEN 82944 is a 5 Amp, 500 Volt Amp-Trap ATQ midget time-delay fuse. This fuse is built for circuit protection up to 30 Amps, ensuring safe operation where the short circuit current is capped at 10,000 Amps. The time-delay feature allows for a twelve-second delay at two hundred percent of the rated load, ideal for high inrush current scenarios. Compliance with UL 248-14 and CSA C22.2 standards makes this fuse compatible with Ultrasafe fuse holders.

• Time-delay characteristic for high inrush current circuits.
• Ideal for supplemental protection in lighting, solenoid, motor, and transformer circuits.
• Available in various ratings for diverse applications up to 500 Volt AC.

Product Highlights

This fuse offers essential circuit protection, delay for high currents, and broad application compatibility.

Product Information

Standard Information

• Brand: MERSEN
• MPN: 82944

Technical Specifications

• Voltage Rating: 500 Volt AC
• Current Rating: 5 Amp
• Interrupting Rating: 10 Kiloamp
• Terminal Type: Ferrule
• Diameter: 0.41 Inch
• Length: 1.5 Inch
• Approval: UL 248-14, CSA C22.2
• Mounting Type: Clip
• Body Material: Glass-Melamine Laminate
• Terminal Material: Tin Plated Copper
• Fuse Amps: 5
• Series: Midget ATQ
• Type: Time-Delay
• Element: Dual
• Indicating: No
• Body Style: Ferrule
• Interrupt Rating AC: 10kA IR AC
