Mersen 61036R Single Pole Fuse Block 100A 600V

Product Description

The MERSEN 61036R is a single-pole fuse block rated for 100 amps and 600 volts, designed for use in industrial and commercial electrical distribution systems. Fuse blocks provide a secure, serviceable mount for overcurrent protection devices within panel boards, control cabinets, and disconnect enclosures. This unit is sold in a pack of three, making it practical for multi-circuit installations. At 0.94 pounds per pack, it is lightweight enough for straightforward panel work. Electricians and electrical contractors rely on fuse blocks like this to create reliable, code-compliant connections between fusing elements and downstream conductors.

The 61036R is suited for single-pole branch circuit and feeder applications in residential service panels, commercial control panels, and light industrial equipment enclosures. Its 600-volt rating covers the vast majority of low-voltage distribution scenarios found in North American electrical installations. Each pack contains three blocks, which aligns well with three-phase applications requiring one block per phase or multiple single-phase branch circuits protected by individual fuses.

Key Features

• Rated 100 amps and 600 volts for broad low-voltage distribution coverage
• Single-pole design for individual circuit overcurrent protection
• Sold in a 3-per-pack configuration to support multi-circuit installations
• Compact footprint at 6.38 inches long, 2.56 inches wide, and 10.19 inches tall
• Lightweight assembly at 0.94 pounds per pack for easy handling in tight enclosures

Compatibility

Designed as an OEM-style replacement or new-installation single-pole fuse block for use in low-voltage electrical distribution panels, control enclosures, and disconnect assemblies rated up to 100A and 600V.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the National Electrical Code (NEC) and all applicable local codes. De-energize the circuit and verify absence of voltage with a suitable meter before installing or servicing the fuse block. Ensure conductor terminations are properly torqued to the terminal manufacturer specifications listed on the block itself. Do not exceed the 100A or 600V ratings under any operating condition.

Technical Specifications

• Amperage Rating: 100 amps
• Voltage Rating: 600 volts
• Configuration: Single pole
• Pack Quantity: 3 per pack
• Package Dimensions (L x W x H): 6.38 inches x 2.56 inches x 10.19 inches
• Weight: 0.94 pounds
• UPC: 78200175738

Standard Information

• Brand: MERSEN
• Manufacturer Part Number: 61036R
