Mersen 60305 Add-a-fuse Fuse Block 30A 600V

Product Description

The MERSEN 60305 is an add-a-fuse fuse block rated for 30 amps and 600 volts. It provides a modular supplemental fusing point that can be added to an existing electrical panel or distribution system without replacing the primary disconnect. Electricians use this component to extend overcurrent protection to branch circuits, control circuits, or individual loads where a dedicated fuse holder is required. The 30-amp, 600-volt rating supports a wide range of industrial and commercial applications where supplemental fusing is part of the overcurrent protection scheme.

This fuse block is suited for use in industrial control panels, commercial electrical distribution systems, and machine tool wiring where branch circuit or control circuit fusing must be added to an existing assembly. It is designed for installation by licensed electricians working on panel upgrades, equipment retrofits, or new control panel builds. The modular add-a-fuse design allows fuse capacity to be expanded incrementally without major rewiring.

Key Features

• 30-amp continuous current rating for branch and control circuit protection
• 600-volt rating supports both low- and medium-voltage distribution applications
• Add-a-fuse modular design allows supplemental fusing points to be added to existing systems
• Compact fuse block form factor fits standard panel and enclosure mounting arrangements

Compatibility

Designed as an OEM-style supplemental fuse block for use in industrial control panels and commercial electrical distribution assemblies requiring 30-amp, 600-volt overcurrent protection.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the National Electrical Code (NEC). De-energize and lockout/tagout the panel or enclosure before installing or replacing any fuse block. Verify that the circuit conductors and connected loads are rated to match the 30-amp, 600-volt specifications of this fuse block before energizing. Follow the manufacturer's torque and termination guidelines for all conductor connections.

Technical Specifications

• Current Rating: 30 amps
• Voltage Rating: 600 volts
• UPC: 78200175671

Standard Information

• Brand: MERSEN
• Manufacturer Part Number: 60305
