Mersen 30323R FER Open Style Fuse Block 600 VAC/VDC 30 A Class CC

Product Description

The Mersen 30323R is an open style fuse block designed for use with 600 VAC/VDC systems. This product accommodates 30 A fuses and supports wire sizes between 14 to 10 AWG. Its robust design ensures it fits into various applications requiring safe and reliable circuit protection.

• Compatible with 600 VAC/VDC systems
• Supports wire sizes from 14 to 10 AWG
• Can accommodate various fuse sizes, including midget and Class CC

Product Highlights

The Mersen 30323R fuse block is adaptable for use with different mounting types and features high dielectric strength materials for enhanced safety.

Product Information

Standard Information

• Brand: Mersen
• MPN: 30323R

Technical Specifications

• Voltage Rating: 600 VAC/VDC
• Amperage Rating: 30 A
• Wire Size: 14 to 10 AWG
• Fuse Length: 1-1/2 in
• Fuse Diameter: 13/32 in
• Number of Poles: 3
• Temperature Rating: 125 deg C
• Material: Glass Reinforced Polycarbonate
• Mounting Type: DIN Rail/Threaded
• Connection Type: Pressure Plate/Double Quick-Connect
• Class: CC
• Series: 303
• Country of Origin: MX
• Standards: UL 4248-4, CSA Class 6225, RoHS Compliant
