Mersen 30311R 303 Series Class CC Midget Fuse Block 30A 600V Screw with Double Quick Connects

Product Description

The Mersen 30311R Class CC Midget Fuse Block is designed for robust circuit protection. It features a 1-pole configuration with a 30A load capacity and a voltage rating of 600V. This fuse block offers versatile connection options including screw terminals with double quick connects, ensuring reliable electrical connections for a variety of applications.

• High compatibility with 1-1/2 inch by 13/32 inch fuses
• Constructed from glass filled polycarbonate for enhanced durability
• Supports DIN rail mounting for easy installation

Product Highlights

Equipped for high-performance with a short-circuit current rating of 200kA and operational at 50/60 Hz frequency range. The unit's reinforced clip design secures connections and withstands rigorous use.

Product Information

Standard Information

• Connection Type: Screw with reinforced clip
• Material: Glass filled polycarbonate

Technical Specifications

• Voltage: 600V AC/DC
• Amperage: 30A
• Mounting: DIN Rail
• Phase: 1
• Temperature Rating: 125°C
• Flammability Rating: UL 94V-0
• Origin: Made in Mexico
