Merit Brass TRS6/10R Time Delay Fuse 6/10A 600V

Product Description

The MERIT BRASS TRS6/10R is a time delay fuse rated at 6/10 amp and 600 volts, classified under the RK5 fuse class. Time delay fuses in this class are designed to withstand brief inrush currents without nuisance tripping while still providing reliable overcurrent protection for branch circuits and equipment. The RK5 classification indicates a rejection-style fuse body that prevents installation in non-RK-rated fuse holders, reducing the risk of misapplication. Licensed electricians and electrical contractors install this type of fuse during panel work, equipment service, and circuit protection upgrades.

This fuse is suited for use in residential, commercial, and light industrial electrical systems where low-amperage branch circuit protection is required. The 600-volt rating makes it appropriate for both single-phase and three-phase applications within that voltage range. It is commonly used to protect motors, transformers, and sensitive electrical components where startup inrush current would otherwise cause a standard fuse to blow prematurely.

Key Features

• 6/10 amp (0.6 A) current rating for low-amperage circuit protection
• 600-volt rating suitable for single-phase and three-phase systems
• RK5 rejection-style class prevents use in non-compatible fuse holders
• Time delay design tolerates motor and transformer inrush without nuisance opening

Compatibility

Designed as an OEM-style replacement for RK5-class time delay fuses in standard rejection-style fuse holders rated for 600 volts and 6/10 amp service.

Installation Notes

Installation should be performed by a licensed electrician in accordance with applicable NEC requirements. Always de-energize and lock out the circuit before removing or installing a fuse. Confirm the fuse holder is rated for RK5-class rejection-style fuses before installation. Do not substitute a fuse of a higher amperage rating than the circuit is designed for.

Technical Specifications

• Current Rating: 6/10 amp
• Voltage Rating: 600 volts
• Fuse Class: RK5
• Fuse Type: Time Delay
• UPC: 78200174856

Standard Information

• Brand: MERIT BRASS
• Manufacturer Part Number: TRS6/10R
