Merit Brass ADI-12 Back-Up Flange, 3/4 in

Product Description

Merit Brass ADI-12 is a back-up flange designed for pipe applications. The product offers a nominal size of three-quarters of an inch with an inside diameter of one point eleven inches. It has a thickness of one-half inch, and a bolt circle measuring two and three-quarters inches. This flange includes four bolt holes for secure installation and an outside diameter of three and seven-eighths inches. Constructed from ductile iron, this import product is suitable for various plumbing and HVAC applications.

• Nominal size: 3/4 in
• Material: Ductile iron
• Four bolt holes for secure installation

Product Highlights

The Merit Brass ADI-12 ensures reliable performance in pipe systems.

Product Information

Standard Information

• Brand: Merit Brass
• Manufacturer: Merit Brass

Technical Specifications

• Nominal Size: 3/4 in
• Inside Diameter: 1.11 in
• Outside Diameter: 3-7/8 in
• Thickness: 1/2 in
• Bolt Circle Diameter: 2-3/4 in
• Number of Bolt Holes: 4
• Bolt Hole Size: 2-3/4 in
• Domestic/Import: Import
