Merit Brass A635-24 Stainless Steel Threaded Flange 1-1/2 Inch 316/316L

Product Description

Merit Brass model A635-24 presents a stainless steel threaded flange, ideal for creating secure, leak-proof joints in piping systems. Its 316/316L grade stainless steel composition offers excellent corrosion resistance and durability, making it suitable for a wide range of industrial applications.

• Threaded for straightforward installation
• Designed for piping systems that require frequent disassembly
• Pressure class 150 lb suitable for moderate pressure applications

Product Highlights

This flange is characterized by its robust raised-face design which enhances the pressure containment capability. The flange facilitates easy access to the piping system for cleaning, inspection, or modification.

Product Information

Standard Information

• Brand: Merit Brass
• MPN: A635-24

Technical Specifications

• Material: 316/316L Stainless Steel
• Size: 1-1/2 inches NPT Female
• Pressure Class: 150 lb
• Connection Type: Thread
• Thickness: 0.69 inches
• Bolt Circle Diameter: 3.88 inches
• Number of Bolt Holes: 4
• Hub Diameter: 2.56 inches
• Length Through Hub: 0.88 inches
