Merit Brass 8016-300 Aluminum Pipe Nipple 1x3 in Sch 40

Product Description

The MERIT BRASS 8016-300 is a 6061 aluminum pipe nipple designed for use in piping systems that require lightweight, corrosion-resistant threaded connections. Measuring 1 inch nominal pipe size by 3 inches in length, this Schedule 40 nipple is threaded on both ends, making it ready for immediate installation between fittings, valves, or equipment connections. The 6061 aluminum alloy construction provides solid strength-to-weight performance and resists corrosion in a range of service environments. At 0.128 pounds, it is significantly lighter than comparable steel nipples. OSHA-standards compliance makes it suitable for industrial and commercial installations where safety standards are enforced.

This nipple is appropriate for use in compressed air, pneumatic, and low-pressure fluid piping systems where aluminum is an acceptable material. It is commonly installed by pipefitters and plumbers in industrial facilities, HVAC mechanical rooms, and process piping applications. The Schedule 40 wall thickness suits standard-pressure service lines. It is sold as an individual unit and is suitable wherever a short close nipple or space nipple is needed to connect two threaded female fittings in tight quarters.

Key Features

• 6061 aluminum alloy construction for corrosion resistance and light weight
• Schedule 40 wall thickness rated for standard service pressures
• Threaded on both ends for direct connection between female-threaded fittings
• 1 inch nominal pipe size by 3 inches length for compact installations
• OSHA-compliant for use in regulated industrial and commercial environments
• Lightweight at 0.128 pounds, reducing load on supported piping runs

Compatibility

Designed as an OEM-style replacement or new-installation component for 1 inch NPT threaded piping systems using Schedule 40 aluminum pipe and fittings.

Installation Notes

Installation should be performed by a licensed pipefitter or plumber following applicable codes including OSHA and local mechanical codes. Depressurize and isolate the piping system completely before removing or installing any threaded components. Use thread sealant or PTFE tape rated for aluminum and the intended service fluid. Avoid overtightening, which can crack aluminum threads; hand-tighten and then advance with a pipe wrench only as needed to achieve a leak-free seal.
