Merit Brass 1068335 Raised Face Pipe Flange 3 in Nominal 150 lb Import

Product Description

The Merit Brass A635-48 is a raised face pipe flange used in various piping systems. This product features a nominal size of three inches and is made from durable 316/316L stainless steel, which provides excellent resistance to corrosion. It includes a threaded connection type and is rated for a pressure class of 150 lb. This flange meets ANSI B16.5, ASME SA182, and ASTM A182 standards for quality and performance.

• Made from 316/316L stainless steel for enhanced durability.
• Threaded connection simplifies installation.
• Meets ANSI and ASME standards for reliable performance.

Product Highlights

This flange is suitable for industrial and commercial use, ensuring strength and reliability in pressure applications.

Product Information

Standard Information

• Brand: Merit Brass
• Nominal Size: 3 in

Technical Specifications

• Material: 316/316L Stainless Steel
• Connection Type: Thread
• Pressure Class: 150 lb
• Bolt Circle Diameter: 6 in
• Bolt Hole Size: 5/8 in
• Hub Diameter: 4-1/4 in
• Length Through Hub: 1.19 in
• Number of Bolt Holes: 4
• Outside Diameter: 7-1/2 in
• Thickness: 1.19 in
• Type: Raised Face
• Domestic/Import: Import
• Standards and Approvals: ANSI B16.5 | ASME SA182 | ASTM A182
