Merit Brass 1068307 Crosby M8-1.25 x 15.20 mm HR-1000M Swivel Hoist Ring - 400 kg WLL

Product Description

The Merit Brass Crosby HR-1000M Swivel Hoist Ring with MPN 1068307 is suitable for lifting applications. It is constructed with alloy steel, ensuring strength and longevity. The forged bail comes with a Product Identification Code (PIC) for easy tracking. This hoist ring has been proof-tested to two and a half times its Working Load Limit (WLL). It maintains a reliable performance at any angle and can support a maximum weight limit of four hundred kilograms.

• All components are made of quenched and tempered alloy steel.
• Includes a Product Identification Code (PIC) on the forged bail.
• Guaranteed performance through proof-testing at two and a half times the WLL.

Product Highlights

This hoist ring is designed for overhead lifting, making it ideal for various industrial applications.

Product Information

Standard Information

• Brand: Merit Brass
• Model: HR-1000M

Technical Specifications

• MPN: 1068307
• Size: M8
• WLL (kg): 400
• Safety Factor: 5:1
• Overhead Lifting Rated: Yes
• Overall Width: 57.7 mm
• Inside Length: 35.1 mm
• Thread Type: Metric
• Thread: 15.20 mm
• Bail Size: 11.2 mm
• Approx. Weight: 0.3 kg
