Merit Brass 01606-1612 Pipe Tee 316L Ss Butt Weld Sch 10

Product Description

The MERIT BRASS 01606-1612 is a reducing pipe tee manufactured from 316L stainless steel for use in high-purity and corrosion-resistant piping systems. The fitting measures 1 inch by 3/4 inch and connects via butt weld ends on all three outlets, making it suitable for permanent, full-penetration welded assemblies. Built to Schedule 10 wall thickness, the 01606-1612 is designed for process, industrial, and mechanical piping applications where material integrity and weld quality are critical. Certified welders and licensed pipefitters are the primary installers for this fitting type.

This reducing tee is used in commercial and industrial piping systems where a branch takeoff at a reduced diameter is required. Schedule 10 wall thickness makes it appropriate for moderate-pressure service in process lines, chemical handling systems, food-grade installations, and marine or coastal environments where 316L stainless steel's elevated molybdenum content provides added corrosion resistance. The butt weld connection style suits applications where threaded or mechanical fittings are not permissible by code or specification.

Key Features

• 316L low-carbon stainless steel construction for superior corrosion resistance in aggressive environments
• Butt weld end connections on all outlets for full-penetration, permanent welds
• Schedule 10 wall thickness suited for moderate-pressure piping systems
• Reducing configuration: 1 inch run by 3/4 inch branch
• Single-piece solid construction with no threaded joints or mechanical seals

Compatibility

Designed as an OEM-style replacement or new-installation fitting for Schedule 10 stainless steel butt weld piping systems with 1 inch run and 3/4 inch branch connections.

Installation Notes

Installation requires a certified welder using procedures appropriate for 316L stainless steel and the applicable piping code, such as ASME B31.3 for process piping or ASME B31.1 for power piping. Purge the line with an inert gas during welding to prevent internal oxidation of the stainless steel. De-energize and fully isolate the piping system, including pressure relief and drain-down, before cutting into any existing line. Post-weld passivation or pickling may be required per project specifications.
