Mencom PCG-M12R Cable Gland (0.079 - 0.196 in)

Product Description

Mencom PCG-M12R is a plastic M12 cable gland that provides strain relief and environmental sealing for cable connections. It accepts cables 0.079–0.196 in (2–5 mm), mounts with an M12 x 1.5 thread, and is rated IP68 for dust and water protection. The gland includes a locknut, neoprene grommet, and is rated to 5 BAR submersion with a temperature range of -20 C to 100 C.

• IP68 ingress protection (submersion to 5 BAR) and neoprene grommet for environmental sealing
• Fits cable diameters 0.079–0.196 in (2–5 mm); mounting thread M12 x 1.5 and includes locknut
• Plastic construction with 3.75 Nm tightening torque; temperature range -20 C to 100 C; UL and CUL recognized

Product Highlights

M12 threaded plastic cable gland providing IP68 sealing and strain relief for 2–5 mm cables

Product Information

Standard Information

• Brand: MENCOM
• Manufacturer Part Number: PCG-M12R

Technical Specifications

• Brand: Mencom
• Manufacturer Part Number: PCG-M12R
• Product Type: Cable gland
• Material: Plastic
• Grommet Material: Neoprene
• Mounting Thread: M12 x 1.5
• Thread Type: Metric
• Cable Diameter Range: 0.079 - 0.196 in (2 - 5 mm)
• Ingress Protection: IP68 (submersion up to 5 BAR)
• Rated Pressure: 5 BAR
• Temperature Range: -20 C to 100 C
• Tightening Torque: 3.75 Nm
• Locknut Included: Yes
• Approvals: UL recognized; CUL recognized
• Mounting Hole Clearance: 12.5 mm
• Weight: 0.0042 lb
• Compatibility: Compatible with ILME hoods
• UNSPSC Code: 26120000
• Gender: Male
• Series: Plastic Gland
