Mencom CYMA-50 Male Crimp Contact Pin 200 A (1 AWG)

Product Description

The Mencom CYMA-50 is a male crimp contact pin for MIXO rectangular connectors. It is silver-plated and rated for 200 A, sized to accept 1 AWG conductors with a crimp termination. The contact operates across a temperature range of -40 C to +125 C and is intended for modular inserts and frames used in industrial automation quick-disconnect connections. A crimp die set is available for the 200 A pin.

• Silver-plated male contact with crimp termination for 1 AWG conductors
• 200 A amperage rating; compatible with ILME MIXO series inserts and frames
• Operating temperature -40 C to +125 C; intended for industrial automation quick-disconnects

Product Highlights

200 A silver-plated male crimp contact for 1 AWG in MIXO rectangular connector systems; operating range -40 C to +125 C.

Product Information

Standard Information

• Brand: MENCOM
• Manufacturer Part Number: CYMA-50

Technical Specifications

• Brand: Mencom
• Manufacturer: Mencom
• Manufacturer Part Number: CYMA-50
• Model: CYMA-50
• Component Type: Contact Pin
• Product Type: Rectangular Connector Contact
• Series: MIXO
• Gender: Male
• Contact Plating: Silver
• Termination: Crimp
• Amperage Rating: 200 A
• Wire Gauge (AWG): 1
• Operating Temperature: -40 C to +125 C
• Compatible With: MIXO series inserts and frames
• Crimp Die Availability: Die set available for 200 A pin
