Mcguire LFBV2165CCSS20 Quarter-Turn Brass Ball Valve Lavatory Supply

Product Description

The Mcguire LFBV2165CCSS20 is a quarter-turn brass ball valve designed specifically for lavatory applications. This valve features a quarter-turn operation for easy use and is made from durable brass. It comes with a flange and a convertible triangle handle for added versatility. The product is compliant with industry standards and is certified to NSF/ANSI/CAN 61 standards with low lead levels.

• Quarter-turn operation for quick adjustments.
• Constructed from durable brass for long-lasting use.
• Meets AB100 standards for safety.

Product Highlights

This valve is a reliable choice for installing and managing water flow in lavatory settings.

Product Information

Standard Information

• Brand: Mcguire
• MPN: LFBV2165CCSS20

Technical Specifications

• Series: Convertible II
• Type: Lavatory
• Construction Type: Pipe x Compression
• Style: Convertible Quarter Turn
• Inlet Size: 1/2 inches
• Inlet Type: IPS
• Outlet Size: 3/8 inches
• Outlet Type: OD
• Operating Pressure Min (psi): 20
• Operating Pressure Max (psi): 125
• Operating Temperature Min (°F): 40
• Operating Temperature Max (°F): 140
• Maximum Temperature: 180 °F max during high-temperature system flush
• Material: Brass
• Operation Type: Quarter turn
• Flange Type: Shallow
• Flange Material: Steel
• Handle Type: Convertible Triangle
• Ball Material: Brass
• Ball Seat: Teflon
• Body Material: Machined brass
• Handle Material: Chrome Plated Zinc
• Handle Screw Material: Brass
• Riser Type: 20 in Stainless Steel Braided
• Stem Type: Brass
• Stem Material: Brass
• Finish: Chrome
• Industry Standards/Certifications: AB100 Compliant, NSF/ANSI/CAN 61: Q < 0.5 µg
• IAPMO Listed: Yes
• Lead Law Compliance Level: Lead Free and Lead Leaching Compliant
• Water Supply Connector Type: Sink
• End Connection 1: OD Tube
• End Connection 2: OD Tube
