McGill SB 22222 W33 22200 Series Spherical Roller Bearing

Product Description

The McGill SB22222W33 is a spherical roller bearing from the 22200 series. This model features a straight bore design with a bore diameter of one hundred ten millimeters and an outer diameter of two hundred millimeters. It is suited for various industrial applications where radial support is necessary.

• Round bore type
• Standard internal clearance
• Lubrication groove and holes for effective lubrication

Product Highlights

This spherical roller bearing is built to accommodate heavy radial loads while allowing for some axial movement. It is particularly useful in applications involving rotating machinery.

Product Information

Standard Information

• Brand: McGill
• MPN: SB22222W33

Technical Specifications

• Inside Diameter: 110 mm
• Outside Diameter: 200 mm
• Overall Width: 53 mm
• Weight: 15.9 LB
• Dynamic Load Rating: 100000 lbf
• Static Load Rating: 124000 lbf
• Limiting Speed (Oil): 2200 rpm
• Limiting Speed (Grease): 1100 rpm
