Product Description
The McGill GR24N is a needle roller bearing designed for smooth operation and efficiency in various applications. This bearing features a bore diameter of 1.5000 inches and an outside diameter of 2.0625 inches, with a width of 1.0000 inches. It is suitable for use in systems where precision and reliability are essential.
- Machined race needle bearing with full complement of center-guided needle rolling elements.
- Annular lubrication groove for easy maintenance.
- Narrow width configuration allows for space-saving installations.
Product Highlights
This product provides a robust solution for rotating applications, offering high load capacities and low friction for various industrial uses.
Product Information
Standard Information
Technical Specifications
-
Bore Diameter: 1.5000 in
-
Outside Diameter: 2.0625 in
-
Overall Width: 1.0000 in
-
Cage Material: No retainer
-
Max RPM: 4000 rpm
-
Radial Dynamic Load Capacity: 7150 lbf
-
Operating Temperature Range: -20 to 250 °F
-
Standards Met: ABMA, ISO
