McGill GR20N GR 20 N Needle Roller Bearing - 1.2500 in Bore, 1.7500 in OD, 1.0000 in Width

Product Description

The McGill GR20N is a needle roller bearing known for its precision and durability. It is designed with a bore size of one point two five inches, an outside diameter of one point seven five inches, and a width of one inch. This bearing is suitable for various applications requiring high load capacity and low friction.

• Features a full complement of center-guided needle rolling elements.
• Designed with an annular lubrication groove to enhance performance.
• Narrow width configuration for versatility in use.

Product Highlights

The GR 20 N bearing supports efficient operation in mechanical systems where space and load management are critical.

Product Information

Standard Information

• Brand: McGill
• MPN: GR20N

Technical Specifications

• Bore Diameter: 1.2500 in
• Outside Diameter: 1.7500 in
• Overall Width: 1.0000 in
• Weight: 0.25 lbs
• Capacity for Static Load: 17000 lbf
• Capacity for Dynamic Load: 6500 lbf
• Max RPM: 4800 rpm
• Operating Temperature Range: -20 to 250 °F
