MCDONNELL & MILLER 126600 Model 221 Water Feeder 3/4 Inch

Product Description

The McDonnell & Miller 126600 Model 221 Water Feeder is a key component for ensuring efficient operation of boiler receiver tanks. This float-operated, make-up water feeder is directly mountable to receiver tanks, which simplifies installation by eliminating the need for equalizing connections.

• Provides a continuous feed action with a soft seat for a positive seal
• Supports a maximum water supply pressure of 150 psi and a maximum vessel pressure of 35 psi
• Features a large mounting flange of eight and a half inches in diameter with six bolt holes measuring over half an inch

Product Highlights

Designed for robust performance, the McDonnell & Miller Model 221 includes a maximum inlet water temperature of 120 degrees Fahrenheit. It is perfect for systems requiring reliable water feeding without manual intervention.

Product Information

Standard Information

• Brand: McDonnell & Miller
• MPN: 126600

Technical Specifications

• Connection type: Threaded
• Connection size: 3/4 inch
• Max Water Temperature: 120°F
• Max Water Pressure: 100 psi
• Weight: 20.36 pounds
