Mastercool 94661 Black Series Mini-Fold Compact 2-Way Aluminum Manifold

Product Description

The Mastercool 94661 Black Series Mini-Fold Compact 2-Way Aluminum Manifold offers essential pressure and temperature calculations displayed on a blue backlit LCD. This compact device is built from aluminum and features numerous functionalities including automatic shut-off, unit conversion, and an over range alarm. It supports a wide range of refrigerants up to ninety-one types, such as R134a, R410a, and R22.

• Compact design with black anodized aluminum block.
• Performs calculations for various pressure and temperature readings.
• Unit conversion for different measurement standards.

Product Highlights

This manifold is suitable for HVAC professionals looking for portability and accuracy in refrigerant measurements.

Product Information

Standard Information

• Brand: Mastercool
• MPN: 94661

Technical Specifications

• Pressure Range: Low -14.5 to 500 psi, High -14.5 to 800 psi
• Resolution: 0.5 psi
• Accuracy: +/-0.5% FS
• Measurement Units: MPa, kPa, bar, psi, kg/cm2, inHg
• Temperature Unit: °C/°F
• Operating Temperature: -10°C to 60°C
• Battery: CR2450
• Battery Life: Approximately 6 months
• Sampling Rate: 1 second
• Display Size: 30 mm x 17 mm LCD
• Fittings: 1/4” SAE flare fittings
• Number of Valves: 2
• Refrigerants Supported: 91 types including R12, R1234yf, R134a
