Martin TS842 Steel Spur Gear - B - 8 Diametral Pitch - 42 Teeth - 1 to 2-1/8 in Bore - w/o Keyway

Product Description

The Martin TS842 Steel Spur Gear is a durable component designed for mechanical power transmission. This gear features a bore size ranging from one inch to two point one two five inches and is made from reliable steel material, ensuring strength and longevity in various applications.

• Made from steel for durability
• Twenty-degree pressure angle
• Reborable design without keyway

Product Highlights

This spur gear is ideal for use in parallel shaft applications, offering ease of integration into existing systems.

Product Information

Standard Information

• Material: Steel
• Availability: Available to order

Technical Specifications

• Hub Diameter: 3.5 inches
• Overall Diameter: 5.5 inches
• Bore Size: 1.000 inch
• Number of Teeth: 42
• Pitch Diameter: 5.25 inches
• Diametral Pitch: 8
• Pressure Angle: 20 degrees
• Weight: 11.4 lbs
