Martin TB18L100 Taperlock Bushed Timing Pulley - 0.38 in Pitch, 1 in Belt Width, 18 Teeth

Product Description

The Martin TB18L100 is a Taperlock bushed timing pulley. Its primary purpose is to drive timing belts effectively using its precision-engineered grooves. This pulley has a belt pitch of zero point three eight inches and a width of one inch. It features a total of eighteen teeth and an outside diameter of two point one one nine inches.

• Bushing Type: Taper-Lock
• Hub Type: A
• Belt Size: L

Product Highlights

The Martin TB18L100 is suitable for various applications where timing belts are used. Its design allows for smooth engagement and minimal friction between the belt and the pulley. It is essential to use at least one flanged pulley to prevent any riding off of the belt due to its inherent side thrust.

Product Information

Standard Information

• Brand: Martin
• MPN: TB18L100

Technical Specifications

• Belt Pitch: 0.38 inches
• Belt Width: 1 inch
• Outside Diameter: 2.119 inches
• Number of Teeth: 18
• Bushing Series: 1008
• Bore Type: Bushed
• Material: Steel
• Weight: 0.7 LB
