Martin SRL225 One-Piece Jaw Coupling Spider 225 Coupling 1.015 in L 5 in OD

Product Description

The Martin SRL225 is a one-piece jaw coupling spider designed for size 225 couplings. It features a length of one point zero fifteen inches and an outer diameter of five inches. This product is built to handle a maximum speed of three thousand six hundred revolutions per minute and lasts at a torque rating of two thousand two hundred sixty-eight inch-pounds.

• Designed for ML and MS Series Flexible Jaw Couplings
• Temperature rating ranges from negative forty to two hundred twelve degrees Fahrenheit
• Constructed from rubber for durability and performance

Product Highlights

The Martin SRL225 coupling spider allows for easy installation without lubrication while ensuring no metal-to-metal contact. It is suitable for applications with angular or parallel misalignment of shafts, promoting smooth power transmission.

Product Information

Standard Information

• Brand: Martin
• Type: One-Piece

Technical Specifications

• Application: For size 225 jaw coupling
• Coupling Size: 225
• Jaw Type: Curved
• Length: 1.015 in
• Material: Rubber
• Maximum Speed: 3600 rpm
• Number of Bolts: 6
• Series: SRL
• Suitable For Use With: ML and MS Series Flexible Jaw Coupling
• Temperature Rating: -40 to 212 deg F
• Torque Rating: 2268 (MS)/29208760 (ML) in-lb
