Martin S2064 External Tooth Spur Gear - 20 DP, 14.5 Degree PA, 64 Teeth, 0.375 in Face, 3/8 to 1-1/4 in Bore

Product Description

The Martin S2064 external tooth spur gear is designed for various mechanical power transmission applications. This gear features sixty-four teeth and a face width of zero point three seven five inches. It can accommodate a bore diameter ranging from three eighths to one and one fourth inches and is made from durable steel. This gear is reboreable, allowing for adaptable use in multiple setups.

• Compatible with ANSI Standard B15.1
• Manufactured from high-quality steel
• Pitched diameter is three point two inches

Product Highlights

This spur gear is ideal for use in machinery requiring reliable power transfer. Its sturdy construction ensures longevity and performance in demanding environments.

Product Information

Standard Information

• Brand: Martin
• Country of Origin: United States

Technical Specifications

• MPN: S2064
• Diametral Pitch: 20
• Pitch Diameter: 3.2 in
• Outside Diameter: 3.3 in
• Face Width: 0.375 in
• Number of Teeth: 64
• Bore Diameter: 3/8 to 1-1/4 in
• Hub Type: Hub w/ No Screw
• Hub Projection: 1/2 in
• Overall Width: 7/8 in
