Martin 80Q20H Bushing Bore Roller Chain Sprocket - Split Taper, 80 / 1 in, 20 Teeth, Q1 Bushing

Product Description

The Martin 80Q20H is a split taper bushing roller chain sprocket. It includes a bore size range from three-quarters of an inch to two and eleven-sixteenths inches. The sprocket is designed with twenty teeth and is made from high carbon steel.

• Compatible with ANSI standards.
• Precision machining for quality performance.
• Interchangeable with other manufacturer bushings.

Product Highlights

This roller chain sprocket provides a reliable option for mechanical power transmission tasks. Its precise design ensures longevity and compatibility with various applications.

Product Information

Standard Information

• Brand: Martin
• Country of Origin: United States

Technical Specifications

• MPN: 80Q20H
• Chain Number & Pitch: 80 / 1 in
• Number of Teeth: 20
• Pitch Diameter: 6.3925 in
• Hub Diameter: 4-1/8 in
• Overall Width: 2-25/32 in
• Outside Diameter: 6.9140 in
• Length Through Bore: 1.7500 in
