Martin 80BTB25 Bushing Bore Roller Chain Sprocket - Taper Locking, 80 / 1 in, 25 Teeth, 2517 Bushing

Product Description

The Martin 80BTB25 is a taper locking bushing bore roller chain sprocket designed for standard roller chain applications. It features a robust construction with twenty-five teeth and a pitch diameter of approximately seven point nine inches. This sprocket is made from steel and offers a bushing bore range of one half to two and a half inches, providing versatility in installation.

• Steel material for durability
• Precision machining for quality
• Interchangeable with other manufacturers' taper bushings

Product Highlights

The Martin 80BTB25 is ideal for use in mechanical power transmission systems, ensuring reliable performance and long-lasting service life.

Product Information

Standard Information

• Brand: Martin
• Origin: United States

Technical Specifications

• MPN: 80BTB25
• Hub Diameter: 4-1/4 in
• Overall Width: 1-3/4 in
• Pitch Diameter: 7.9787 in
• Tooth Width: 0.575 in
• Number of Teeth: 25
• Bushing Bore Range: 1/2 to 2-1/2 in
• Chain Number & Pitch: 80 / 1 in
• Surface Treatment: Protective Coating
• Length Through Bore: 1.7500 in
• Number of Hubs: 1
