Martin 80BTB17 Bushing Bore Roller Chain Sprocket - Taper Locking, 80 / 1 in, 17 Teeth, 2012 Bushing, Steel Material

Product Description

The Martin 80BTB17 is a bushing bore roller chain sprocket designed for durability and precision. This product features a taper lock design that securely attaches to the shaft, ensuring a reliable connection. Commonly used in mechanical power transmission applications, this sprocket has seventeen teeth and is compatible with standard roller chains.

• Designed with a taper bushing for secure attachment
• Manufactured from high carbon steel for strength
• Meets ANSI standards for performance

Product Highlights

The taper locking feature allows for easy installation and removal without damaging the shaft.

Product Information

Standard Information

• Manufacturer: Martin
• MPN: 80BTB17
• Country Of Origin: United States

Technical Specifications

• Pitch Type: Single
• Tooth Width: 0.575 inches
• Hub Diameter: 4 inches
• Overall Width: 1-1/4 inches
• Number of Hubs: 1
• Pitch Diameter: 5.4422 inches
• Number of Teeth: 17
• Caliper Diameter: 4.7940 inches
• Outside Diameter: 5.9500 inches
• Surface Treatment: Protective Coating
• Bushing Bore Range: 1/2 to 2 inches
• Length Through Bore: 1.2500 inches
• Chain Number & Pitch: 80 / 1 inch
• Chain / Sprocket Type: Standard Roller Chain
• Manufacturer UPC Number: 697950032184
• Storage Dimension Width: 6 inches
• Storage Dimension Height: 1.3125 inches
• Storage Dimension Length: 6 inches
