Martin 80BTB13 Bushing Bore Roller Chain Sprocket - Taper Locking, 80 / 1 in, 13 Teeth, 1615 Bushing, Steel Material

Product Description

The Martin 80BTB13 Bushing Bore Roller Chain Sprocket is designed for reliable performance in mechanical power transmission applications. This sprocket features a taper locking mechanism, ensuring a secure fit to the shaft while allowing for easy removal and installation. It is suitable for roller chains with a pitch of 1 inch and is crafted from high-quality steel material.

• Type: Taper Locking Design
• Teeth: Thirteen for efficient power transfer
• Bushing Bore: Compatible with 1 inch diameter shafts

Product Highlights

This sprocket is essential for various mechanical applications, providing a solid connection between chains and shafts. It meets ANSI standards for durability and reliability.

Product Information

Standard Information

• Brand: Martin
• MPN: 80BTB13
• Country of Origin: United States

Technical Specifications

• Tooth Width: 0.575 inches
• Hub Diameter: 3 inches
• Overall Width: 1.5 inches
• Pitch Diameter: 4.1786 inches
• Number Of Teeth: 13
• Length Through Bore: 1.5 inches
• Bushing Bore Range: 0.5 to 1.625 inches
• Chain Number & Pitch: 80 / 1 inch
